Automatic edge sealing shrink packaging machine
Description:
Product Features:
★ The sealing knife adopts imported special materials, and the surface coating adopts DuPont Fron high temperature anti-adhesive material to ensure that the sealing is not cracked and the sealing line is firm;
★ It adopts horizontal and vertical two-group photoelectric, which is convenient to switch. For thin or small products, it can be easily packaged.
★ Automatic feeding, the length can also be automatically adjusted by the combination of photoelectric and timer, equipped with induction motor, automatic coiling waste;
★ When the size of the package is changed, the adjustment is very simple, no need to change the mold and the bag;
★ The sealing knife has an automatic protection function to prevent mis-cutting of the package;
★ The sealing and cutting part is equipped with a plexiglass protective cover and an automatic alarm function, which greatly improves the operator's safety;
★ Sealing and heat shrink packaging are automatically and continuously completed, with stable performance, great manpower saving, reliable quality, high shrinkage efficiency and strong applicability.
Detailed Product Description:
Packing size: L500×W400×H200mm
Furnace cavity size: L1000×W450×H250mm
Packing speed: 20-40 pieces / minute
Net weight: 185kg
Power: 10kw
Power: 380v 50/60Hz
Maximum current: 30A
Machine size: L1300×W715×H1455mm
Application:
The fully automatic L-type sealing and cutting heat shrink packaging machine is a fully automatic unmanned packaging machine, which can be used with automatic packaging line, and can be automatically completed by feeding, bagging, sealing and heat shrinking. High work efficiency, widely used in printing, color boxes, greeting cards, photo albums, photo frames, medicine, electronics, daily chemicals, cosmetics and other mass production industries.
