Stable Performance Plywood Turnover Machine / Four Wheel Pallet Flipper

Brand Name : QTIT

Model Number : CFB-3T

Certification : CCC/CE/SGS

Place of Origin : China

MOQ : Negotiation

Price : Negotiation

Payment Terms : T/T or western Union

Supply Ability : 100pcs per month

Delivery Time : 10 working days after received your payment

Packaging Details : Packed in stretch film firstly,and then reinforced with wooden case for outer packing

Name : Plywood Turnover Machine

Feature : Stable Performance

Steel plate size : length 1250mm, width 780mm, height 100-500mm;

Type : Chain Type

Turnover angle : 180°

Weight : 2.5T

Contact Now

Stable Performance Plywood Turnover Machine / Four Wheel Pallet Flipper


Plywood Turnover Machine Main features:

  1. The double-row chain drive makes the turning part of the turning machine work more smoothly and reliably.
  2. Using super worm gear reducer makes the transmission power of the equipment more safe and reliable.
  3. The four-wheel mechanism with reasonable structure has a stable bearing.
  4. After the flip is completed, the flip ends to automatically stop.
  5. Using the emergency stop button makes it possible to quickly stop the flip in an emergency.
  6. The unit can be stopped at any position during the flipping process.
  7. Products centered into the center of the turning machine working platform
  8. The unique flip surface design ensures that the product fits close to the flipping body, and the turning operation is smooth and safe.
  9. Use a jacking or lowering mechanism.
  10. Using synchronous mechanical structure to ensure uniformity and stability of the whole machine.
  11. Product nature: Pressure does not damage the product itself.

Plywood Turnover Machine Basic data

  1. plate material: stainless steel SUS201
  2. Steel plate size: length 1250mm, width 780mm, height 100-500mm;
  3. Pallet size: 800mm × 700mm × 120mm;
  4. Steel plate and tray integrated;
  5. The entire material weight is around 500KG-3000KG.
  6. Turning machine size: about 2000mm * 900mm * 1650mm.
  7. Machine weight: about 2.5T.
  8. Power supply: 380V, three-phase five-wire.

Plywood Turnover Machine Main configuration

Serial number Name Brand model number Remarks
1 Motor reducer Germany DEMAYR (Hangzhou factory) 1.5KW
2 Hydraulic Taiwan brand or homemade 3.7KW
3 Switch, knob, contactor Schneider Matching motor box
4 Bearing HRB


Main performance indicators

Item number content Indicator requirements Definition and condition of performance guarantee value
1 Single flip time 90 seconds ± 10% Single flip 180° time
2 Maximum turning capacity 3000kg


Equipment spraying
1) Machine: Egg Green GSB05-1426-2001 (instead of GSB G51001-94)
2) The warning part is yellow


Product Tags:

hydraulic upender



mechanical upender


Wholesale Stable Performance Plywood Turnover Machine / Four Wheel Pallet Flipper from china suppliers

Stable Performance Plywood Turnover Machine / Four Wheel Pallet Flipper Images
